Jomar Valve 105-007G P-501G 1-Piece Horizontal Swing Check Valve, 1-1/2 in, Press, 125 lb

Product Description

The Jomar Valve 105-007G is a one-piece horizontal swing check valve designed for plumbing applications. This valve features a cast brass body for durability and low lead compliance. It operates under a pressure class of 125 lb and has a nominal size of one and one-half inches.

• Dezincification resistant brass
• Heavy pattern cast brass construction
• Metal to metal disc seal

Product Highlights

This valve is ideal for preventing backflow in various plumbing systems, ensuring safe and efficient water flow.

Product Information

Standard Information

• Brand: Jomar Valve
• Part Number: J6067

Technical Specifications

• Actuator Type: Spring Assisted
• Body Material: Cast Brass
• Dimensions: 3.4 in H
• End Style: Press
• Inlet to Outlet Length: 5.32 in
• Low Lead Compliance: Yes
• Manufacturing Standards/Approvals: C87850 Body, C69300 Disc, IAPMO PS 117
• Nominal Size: 1-1/2 in
• Package Weight: 63.0 lb
• Pressure Class: 125 lb
• Series: P-501G
• Softgoods Material: EPDM O-Ring, Seal
• Trim Material: Brass
• Type: 1-Piece Horizontal
