Jomar Valve 104-526PG Ball Valve 1-1/4 in Threaded x PEX

Product Description

The JOMAR VALVE 104-526PG ball valve is a T-422G series valve with a 1-1/4 inch nominal size and threaded x PEX connection. This 2-piece standard port valve is constructed with lead-free brass and has a maximum pressure rating of 400 psi WOG. It is suitable for use with water, oil, and gas media.

• Dezincification-resistant brass alloy
• Gland follower and single O-ring stem design
• Blowout-proof stem

Product Highlights

This Jomar ball valve features a lead-free brass body, PTFE seat, and stainless steel stem. It is 100% factory leak tested and certified to ASTM F1960 standards.

Product Information

Standard Information

• Brand: JOMAR VALVE
• Manufacturer Part Number: 104-526PG
• Country of Origin: Domestic

Technical Specifications

• Item Name: Ball Valve
• Series: T-422G
• Type: Standard Port
• Nominal Size: 1-1/4 inch
• Connection Type: Expansion PEX
• Maximum Pressure Rating: 400 psi WOG
• Media: Water, Oil and Gas
• Number of Ports/Ways: 2
• Seat: PTFE
• Body Material: Lead-Free Brass
• Ball Material: Chrome-Plated Lead-Free Brass
• Seal: Buna-N
• Stem: Chrome-Plated Lead-Free Brass
• Construction: 2-Piece
• Packing: Brass
• Actuation/Operator: Lever
• Handle Material: Chrome-Plated Steel
• Temperature Rating: 200 deg F
• Standards/Approvals: ASTM F1960, cUPC Certified, IAPMO/ANSI Z1157-2014, NSF 61-8 and 372, NSF/ANSI 14-2014, RoHS Compliant
