Jomar Valve 100-211XLCG JP-100XLC LF Brass Italian XLC Press Valve 4 inches

Product Description

The JOMAR VALVE 100-211XLCG JP-100XLC LF Brass Italian XLC Press Valve is a 4-inch, 2-piece, full port ball valve with a press XLC connection. It has a pressure rating of 200 psi and a temperature rating of 250 degrees F. The valve is suitable for use with water, oil, and gas media. The valve features dezincification-resistant brass alloy.

• Triple sealing stem with 2 FKM O-rings and second generation PTFE seats
• Blow-out proof stem design
• 100% leak tested
• Wetted surfaces contain less than 0.25% lead content

Product Highlights

This Jomar Valve is 100% made in Italy and features a leak-proof stem with a lifetime warranty. The valve is constructed from corrosion-resistant brass.

Product Information

Standard Information

• Brand: JOMAR VALVE
• Manufacturer Part Number: 100-211XLCG
• Country of Origin: Italy

Technical Specifications

• Ball Material: TEA coated brass
• Body Material: Brass
• Connection Type: Press XLC
• Finish/Color: Chrome Plated Ball, Geomet Plated Handle
• Gland Material: Brass
• Handle Material: Steel
• Nominal Size: 4 in
• O-Rings: Viton
• Packing Material: TFM 1600 Hostaflon
• Pressure Rating: 200 psi
• Seal Material: Teflon
• Seat Material: TFM 1600 Hostaflon
• Series: JP-100PxP
• Stem Material: Brass
• Temperature Rating: 250 deg F
• Trim Material: Brass Ball
• Type: 2-Piece, Full Port
• Maximum Pressure Rating: 200 psi WOG
• Media: Water, Oil and Gas
• Opening Size: 4 inch
• Seat: Hostaflon® TFM 1600
• Actuation/Operator: Lever Handle
• Standards/Approvals: Conforms to IAPMO PS 117, Meets ISO 6509
• End Style: Press
• Inlet to Outlet Length: 10.79 in
• Orifice Size: 4 in
• Port Type: Full
