Jomar 500-307 Full Port, 3 Piece 4 Bolt, Swing Out Body, Threaded Connection, 1000 WOG

Product Description

The Jomar 500-307 is a ball valve designed for high-performance applications. This 3-piece valve features a full port design and a swing-out body for easy maintenance. It has a threaded connection and can handle pressures up to 1000 WOG. The stainless steel construction ensures durability and long service life.

• High pressure rating of 1000 psi WOG
• Stainless steel ball and body for corrosion resistance
• Easy access for maintenance with swing-out body design

Product Highlights

This valve is suitable for a range of applications including water, oil, and gas services. Its robust design and high performance make it ideal for both residential and commercial use.

Product Information

Standard Information

• Manufacturer: JOMAR
• MPN: 500-307
• UPC: 662527302618

Technical Specifications

• Nominal Size: 1-1/2 in
• Inlet to Outlet Length: 4.73 in
• Top to Inlet Center: 3.94 in
• Actuator Type: Latch-Lock Handle
• Port Type: Full
• Body Material: Stainless Steel
• Ball Material: Stainless Steel
• Pressure Rating: 1000 psi WOG
• End Style: NPT
• Softgoods Material: Hostaflon TFM/RPTFE
• Trim Material: 316 Stainless Steel Stem and Hostaflon TFM 1600 Seat
• Standards: ANSI B1.20.1/B16.11, API 598, CERT Certified, NACE Certified
