Jomar 160-103 2-piece Full Port Ball Valve 1/2 in Brass

Product Description

The JOMAR 160-103 is a 2-piece, full-port ball valve designed for use in fluid control applications where reliable shutoff and minimal pressure drop are required. The valve features a chrome-plated brass ball, a brass body, and a brass stem with Hostaflon TFM 1600 seat trim. Softgoods are Hostaflon TFM/FKM construction, providing chemical resistance and long service life. Rated at 600 psi WOG, the 160-103 is suited for high-demand plumbing and mechanical systems. End connections are FNPTxUnion FNPT, making it straightforward to install and service in-line without disturbing the surrounding piping. Licensed plumbers and pipefitters are the primary installers for this type of valve.

This valve is appropriate for residential and light commercial plumbing, hydronic heating, and mechanical piping systems where a reliable, compact 1/2-inch shutoff is needed. The Union FNPT outlet allows the valve to be disconnected and serviced without cutting pipe. The included side-tap handle provides a positive open/closed indicator and easy quarter-turn operation. The full-port design keeps flow restriction minimal, making this valve suitable wherever pressure loss is a concern.

Key Features

• 2-piece body construction with Union FNPT outlet for in-line serviceability
• Full-port design minimizes pressure drop across the valve
• 600 psi WOG pressure rating for demanding plumbing and mechanical applications
• Chrome-plated brass ball with brass stem for corrosion resistance and durability
• Hostaflon TFM 1600 seat and TFM/FKM softgoods for chemical compatibility
• Side-tap handle included for quarter-turn operation with clear position indication

Compatibility

Designed as an OEM-style replacement or new-installation ball valve for 1/2-inch FNPTxUnion FNPT plumbing and mechanical piping systems rated up to 600 psi WOG.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable local plumbing codes and the IPC. Shut off the water supply and relieve system pressure completely before removing or installing any valve. Apply thread sealant or PTFE tape to all male NPT threads per standard practice. The Union FNPT connection allows the valve to be removed for service without cutting into the line, simplifying maintenance in tight spaces.

Technical Specifications

• Nominal Size: 1/2 inch
• Pressure Rating: 600 psi WOG
• Port Type: Full Port
• End Style: FNPTxUnion FNPT
• Inlet to Outlet Length: 3.17 inches
• Top to Inlet Center: 1.53 inches
• Body Material: Brass
• Ball Material: Chrome Plated Brass
• Stem Material: Brass
• Seat Trim: Hostaflon TFM 1600
• Softgoods Material: Hostaflon TFM/FKM
• Country of Origin: Import

Standard Information

• Brand: JOMAR
• Manufacturer Part Number: 160-103
