JOMAR 105-208G Horizontal Swing Check Valve, Solder Connection, Class 125, 200 WOG
JOMAR 105-208G Horizontal Swing Check Valve, Solder Connection, Class 125, 200 WOG

JOMAR 105-208G Horizontal Swing Check Valve, Solder Connection, Class 125, 200 WOG

Brand: JOMAR
SKU: 105-208G
Availability: In Stock
truck-svgrepo-com

Ships via Freight in 3-5 Business Days
$82.59
$82.59
Manuals:
LTL Delivery

This product weighs 70 lbs and may require the use of lift gate. If you require a lift gate you will have the option to add one FREE of charge at checkout.

HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The JOMAR 105-208G is a horizontal swing check valve designed for solder connections and rated for Class 125 pressure. It is suitable for both commercial and residential applications. This lead-free valve features a spring actuator and complies with low lead regulations. Its overall length from inlet to outlet is five point ninety-nine inches.

  • Constructed from cast brass with forged brass trim
  • Wetted surfaces contain less than zero point twenty-five percent lead content
  • IAPMO certified and UPC listed

Product Highlights

This check valve is built for high performance in plumbing systems, providing reliable backflow prevention with its robust design.

Product Information

Standard Information

  • Manufacturer: JOMAR
  • MPN: 105-208G

Technical Specifications

  • Actuator Type: Spring
  • Body Material: Cast Brass
  • Trim Material: Forged Brass
  • Nominal Size: 2 inches
  • Pressure Class: 125 lb
  • Series: S-501G
  • Inlet to Outlet Length: 5.99 inches
  • Top to Inlet Center: 2.68 inches
  • End Style: Solder Joint
