JOMAR 104-554PG 2 Piece, Threaded Male x Expansion Pex Connection, 400 WOG

Product Description

The JOMAR 104-554PG is a 2 piece, threaded male x expansion PEX connection designed for high performance in plumbing applications. This product is rated for 400 psi WOG and operates effectively at temperatures up to 200 degrees Fahrenheit.

• Standard port design for optimal flow.
• Constructed with durable brass body and stainless steel components.
• Features PTFE packing for leak resistance.

Product Highlights

This connection is suitable for water, oil, and gas applications, ensuring reliability in various environments.

Product Information

Standard Information

• Manufacturer: JOMAR
• MPN: 104-554PG

Technical Specifications

• Ball Material: 304 Stainless Steel
• Body Material: Brass
• End Style: FNPT x Expansion PEX
• Inlet to Outlet Length: 2.68 inches
• Nominal Size: 3/4 inches
• Port Type: Standard
• Pressure Rating: 400 psi WOG
• Softgoods Material: PTFE/Buna-N
• Temperature Rating: 200 degrees Fahrenheit
• Top to Inlet Center: 1.81 inches
• Trim Material: 304 Stainless Steel Stem and PTFE Seat
• Type: 2-Piece
