Jomar 103-310 T-301 brass thrd gate valve 3 IN

Product Description

The JOMAR 103-310 T-301 Series gate valve features a 3-inch nominal size and FNPT connection. Constructed with a cast brass body, this valve is designed for 200 PSI (WOG) pressure rating. It includes a handwheel operator with a cast iron handle and a brass stem, suitable for residential and commercial applications.

• Gate Valve with Brass Threaded
• Manufactured in ISO-9001 facility
• Solid wedge gate

Product Highlights

Features a cast brass body, handwheel operator, and is NSF certified. Ideal for controlling fluid flow in various applications.

Product Information

Standard Information

• Brand: JOMAR
• Manufacturer Part Number: 103-310

Technical Specifications

• Series/Model: T-301
• Nominal Size: 3 IN
• Connection Type: FNPT
• Pressure Rating: 200 PSI (WOG)
• Body Material: Cast Brass
• Operator Type: Handwheel
• Handle Material: Cast Iron
• Stem Material: Brass
• Trim Material: Cast Brass Disc
• Industry Standards: NSF Certified
• Width: 3.98 IN
• Lead Free: No
• Handwheel Diameter: 5.12 IN
• Top Of Handle To Inlet Center: 8.75 IN
• Model #: 103-310
• Description: 3 in. Non-rising Stem, Threaded Connection, 200 WOG
• Item Number: 103-310
• Brand: Jomar
• Connection: Threaded Connection
• Family: T-301
• Material: Regular Brass
• Size: 3"
