Jomar 100-664G full port 2 piece solder x hose connection stainless steel ball valve 600 WOG 3/4 inch

Product Description

The JOMAR 100-664G is a 2-piece full port ball valve designed for solder x hose connections. It features a 304 stainless steel ball and stem with PTFE seat trim, and a lead-free brass body. Rated for 600 psi WOG pressure, this 3/4 inch nominal valve is suitable for various plumbing applications requiring reliable flow control. Its wetted surfaces contain less than 0.25% lead content, meeting NSF 61-8/372 and IAPMO/ANSI Z1157-2014 standards.

• Cap and chain for easy drain and hose connection
• Blow-out proof stem for enhanced safety
• 100% leak tested for reliable performance

Product Highlights

This 2-piece ball valve offers full port flow, durable lead-free brass construction, and stainless steel internal components for efficient and safe operation in plumbing systems.

Product Information

Standard Information

• Brand: JOMAR
• Manufacturer Part Number: 100-664G
• Country of Origin: Import

Technical Specifications

• Ball Material: 304 Stainless Steel
• Body Material: Lead Free Brass
• End Style: Solder x Hose
• Inlet to Outlet Length: 3.54 in
• Nominal Size: 3/4 in
• Port Type: Full
• Pressure Rating: 600 psi WOG
• Softgoods Material: PTFE/Buna-N
• Top to Inlet Center: 1.94 in
• Trim Material: 304 Stainless Steel Stem and PTFE Seat
• Type: 2-Piece
• Manufacturer: JOMAR
• Certifications: ANSI B1.20.7, ASME/ANSI B16.18, cUPC Listed, IAPMO/ANSI Z1157-2014, MSS SP-110, NSF 61-8/372, NSF/ANSI 14-2014, Conforms to IAPMO PS 117
• Handle Type: Lever
• Family: S-100HSG
• Valve Type: Ball Valve
