Jomar 100-634G Full Port, 2 Piece, Threaded Connection, 600 WOG, Stainless Steel Ball and

Product Description

The Jomar 100-634G is a 2-piece full port ball valve with a threaded connection. This valve is rated for 600 psi WOG and is made from durable stainless steel. It connects using NPT threads, making it suitable for a variety of plumbing applications.

• Two-piece design enhances durability
• 600 psi WOG rating for high-pressure systems
• Compatible with NPT connections

Product Highlights

This valve is designed for leak-proof performance and durability in demanding environments. It features a blow-out proof stem and is 100% leak tested, ensuring reliable operation.

Product Information

Standard Information

• Manufacturer: JOMAR
• Application: Plumbing and fluid control

Technical Specifications

• Ball Material: 304 Stainless Steel
• Body Material: Brass
• End Style: NPT
• Inlet to Outlet Length: 2.36 inches
• Nominal Size: 3/4 inches
• Port Type: Full
• Pressure Rating: 600 psi WOG
• Softgoods Material: PTFE/Buna-N
• Top to Inlet Center: 1.97 inches
• Trim Material: 304 Stainless Steel Stem and PTFE Seat
• Type: 2-Piece
