Jomar 100-408SSG-IH Full Port, 2 Piece, Threaded Connection, Dezincification Resistant Brass w

Product Description

The JOMAR 100-408SSG-IH is a full port, 2 piece ball valve with a threaded connection and dezincification resistant brass construction. It features stainless steel trim and is designed for durability and performance. This valve is 100% leak tested and made in Italy.

• Dezincification Resistant Brass Alloy
• Stainless Steel Trim
• Triple Sealing Stem with 2 FKM O-rings and Second Generation PTFE Seats

Product Highlights

Full port, 2 piece, threaded connection, dezincification resistant brass with stainless steel trim.

Product Information

Standard Information

• Brand: JOMAR
• Manufacturer Part Number: 100-408SSG-IH
• Country of Origin: Italy

Technical Specifications

• Manufacturer: JOMAR
• Dezincification resistant brass alloy: Yes
• Stainless steel trim: Yes
• Triple sealing stem with 2 VITON o-rings and Hostaflon seal: Yes
• Blow-out proof stem: Yes
• 100% leak tested: Yes
• 100% Made in Italy: Yes
• 29 in-Hg vacuum rating: Yes
• Wetted surfaces contain less than .25% lead content: Yes
• MPN: 100-408SSG-IH
• Size: 2"
• Connection Type: Threaded
• Handle Type: Insulated
• Pressure Rating: 600 WOG
• Body Material: Lead Free Brass
• Trim Material: Stainless Steel
• Seat Material: PTFE
• Seal Material: FKM
• Certifications: NSF
• NSF 372: None
• NSF 61-8: None
• NSF 61 ">– Annex G: None
• UL-2043 Certified Insulated Handle: None
• MSS SP-110: None
• ANSI B1.20.1: None
• Brand: Jomar
