Jomar 100-408G 2 Piece Full Port Threaded Connection Dezincification Resistant Brass

Product Description

The Jomar Valve 100-408G is a two-piece, full port ball valve made of dezincification resistant brass. This valve features a threaded connection style and is rated for 500 psi WOG pressure. It has a nominal size of two inches and an orifice size of one point ninety-nine inches. The ball is constructed with TEA coated brass, ensuring durability and resistance to corrosion. The valve measures four point twenty-nine inches from inlet to outlet and three point four inches from the top to inlet center. Key components include a brass body, brass stem, and Hostaflon TFM 1600 seat trim.

• Compact design suitable for various applications
• Triple sealing stem with FKM O-rings and a PTFE seal
• Leak-proof stem lifetime warranty ensures reliability

Product Highlights

This ball valve is designed to provide reliable performance, with a blow-out proof stem and 100% leak testing to guarantee quality. It is also compliant with ANSI, cULus, CSA, and NSF approvals, making it a compliant choice for plumbing professionals.

Product Information

Standard Information

• Manufacturer: JOMAR
• Connection Type: Thread

Technical Specifications

• Ball Material: TEA Coated Brass
• Body Material: Brass
• Nominal Size: 2 in
• Orifice Size: 1.99 in
• Pressure Rating: 500 psi WOG
• Inlet to Outlet Length: 4.29 in
• Top to Inlet Center: 3.4 in
• Trim Material: Brass Stem and Hostaflon TFM 1600 Seat
