Jomar 100-406G 2 Piece Full Port Threaded Connection Dezincification Resistant Brass

Product Description

The Jomar 100-406G is a ball valve featuring a two-piece design and a full port for optimal flow. It is made from dezincification resistant brass, ensuring durability and longevity in various applications. The valve connects via a threaded end style and is suitable for a nominal size of one and one-quarter inches.

• Dezincification resistant brass construction
• 500 psi WOG pressure rating
• Triple sealing with integrated O-rings

Product Highlights

Designed for reliability, the Jomar 100-406G provides a compact solution in plumbing systems, with a blow-out proof stem and lifetime warranty.

Product Information

Standard Information

• Manufacturer: Jomar
• Type: 2-Piece

Technical Specifications

• Nominal Size: 1-1/4 inches
• Ball Material: TEA Coated Brass
• Body Material: Brass
• End Style: FNPT
• Pressure Rating: 500 psi WOG
• Inlet to Outlet Length: 3.22 inches
• Top to Inlet Center: 2.59 inches
• Softgoods Material: Hostaflon TFM/FKM
• Trim Material: Brass Stem and Hostaflon TFM 1600 Seat
