Jomar 100-405SSG-IH Full Port Threaded Lead Free Brass Ball Valve 1 Inch

Product Description

The JOMAR 100-405SSG-IH is a 1 inch, full port, threaded ball valve. Constructed from dezincification resistant brass with stainless steel trim and an insulated handle, this valve is rated for 600 WOG. It features a triple sealing stem and is 100% leak tested.

• Dezincification resistant brass alloy
• Stainless steel trim
• Triple sealing stem with 2 FKM O-rings and Second Generation PTFE Seats

Product Highlights

This lead-free brass ball valve is ideal for various applications, ensuring longevity and peak performance. It is 100% Made in Italy.

Product Information

Standard Information

• Brand: JOMAR
• Manufacturer Part Number: 100-405SSG-IH
• Country of Origin: Italy

Technical Specifications

• Manufacturer: JOMAR
• WOG: 600
• Material: Dezincification resistant brass alloy
• Trim: Stainless steel
• Stem Sealing: Triple sealing stem with 2 VITON o-rings and Hostaflon seal
• Stem Design: Blow-out proof stem
• Testing: 100% leak tested
• Origin: 100% Made in Italy
• Stem Warranty: Leakproof stem - Lifetime Warranty
• Vacuum Rating: 29 in-Hg vacuum rating
• Lead Content: Wetted surfaces contain less than .25% lead content
• MPN: 100-405SSG-IH
• Size: 1"
• Connection Type: Threaded
• Handle Type: Thermal-Block Insulated Locking Handle
• Pressure Rating: 600 WOG
• Body Material: Lead-Free Brass - C27453
• Seat Material: PTFE
• Seal Material: FKM
• Certifications: NSF
• NSF 372: None
• NSF 61-8: None
• NSF 61 ">– Annex G: None
• UL-2043 Certified Insulated Handle: None
• MSS SP-110: None
• ANSI B1.20.1: None
• Item: Ball Valve
• Port: Full Port
• Design Type: 2-Piece
• End Connection: NPT Threaded
• Ball Material: 316 Stainless Steel
• Stem Material: 316 Stainless Steel
• Max Pressure: 500 psi, 150 psi Steam
• Max Temp: 400°F
• Brand: Jomar
