Jomar 100-398THG Full Port, 2 Piece, Mini Valves, 600 WOG, Stainless Steel Ball and Stem

Product Description

The Jomar 100-398THG is a two-piece mini ball valve designed for piping and fittings. This valve has a full port design and can handle pressure up to six hundred WOG. It features a T-handle actuator for easy operation. This valve uses high-quality materials to ensure durability and reliability in various plumbing applications.

• Full port design allows for maximum flow
• 100% leak tested for peace of mind
• Constructed from 304 stainless steel and brass for strength

Product Highlights

This valve is suitable for both residential and commercial plumbing systems. Its compact size makes it easy to install in tight spaces while allowing for efficient water flow.

Product Information

Standard Information

• Manufacturer: JOMAR
• Model: 100-398THG

Technical Specifications

• Actuator Type: T-Handle
• Ball Material: 304 Stainless Steel
• Body Material: Brass
• End Style: MNPT x FNPT
• Inlet to Outlet Length: 1.93 inches
• Nominal Size: 1/4 x 1/8 inches
• Port Type: Full
• Pressure Rating: 600 psi WOG
• Softgoods Material: Buna-N
• Top to Inlet Center: 1.33 inches
• Trim Material: 304 Stainless Steel Stem and PTFE Seat
• Type: 2-Piece
