Jomar 100-297 Full Port, 2 Piece, Threaded Connection, Mini Valves, 600 WOG

Product Description

The Jomar Mini Ball Valve 100-297 features a full port design with a two-piece construction. Its threaded connections allow for easy installation. This valve operates at a pressure rating of six hundred psi WOG and is suitable for various piping applications.

• Two-piece construction for enhanced durability.
• Full port design promotes greater flow rates.
• Lever-operated actuator for straightforward operation.

Product Highlights

The Jomar Mini Ball Valve is ideal for plumbing, heating, and industrial applications where control of fluid flow is necessary.

Product Information

Standard Information

• Brand: Jomar
• MPN: 100-297

Technical Specifications

• Actuator Type: Lever Operated
• Ball Material: Chrome Plated Brass
• Body Material: Brass
• End Style: MNPT x FNPT
• Inlet to Outlet Length: 1.96 inches
• Nominal Size: 1/8 inches
• Orifice Size: 0.31 inches
• Port Type: Full
• Pressure Rating: 600 psi WOG
• Softgoods Material: FKM
• Top to Inlet Center: 1.14 inches
• Trim Material: Brass Stem and PTFE Seat
• Type: 2-Piece
