Jomar 100-113SSG Full Port, 2 Piece, Solder Connection, 600 WOG, Stainless Steel Ball and S

Product Description

The Jomar 100-113SSG is a ball valve made of stainless steel suitable for various plumbing applications. This valve is designed with a full port and features a solder connection that supports a pressure rating of up to 600 WOG. It is a two-piece construction which ensures durability and effective performance in fluid control applications.

• Full port design allows for maximum flow.
• Lead-free brass end connection for safety.
• 150 psi working steam pressure capability.

Product Highlights

This valve is ideal for use in water, gas, and oil applications. It includes a blow-out proof stem and is thoroughly leak tested to ensure reliability.

Product Information

Standard Information

• Manufacturer: Jomar
• MPN: 100-113SSG

Technical Specifications

• Ball Material: 304 Stainless Steel
• Body Material: Brass
• End Style: Solder
• Inlet to Outlet Length: 2.17 inches
• Nominal Size: 1/2 inch
• Orifice Size: 0.59 inches
• Port Type: Full
• Pressure Rating: 600 psi WOG
• Softgoods Material: PTFE/Buna-N
• Top to Inlet Center: 1.81 inches
• Trim Material: 304 Stainless Steel Stem and PTFE Seat
• Type: 2-Piece
