Jomar 100-111SSG Full Port, 2 Piece, Threaded Connection, 600 WOG, Stainless Steel Ball and

Product Description

The Jomar Valve® 100-111SSG is a ball valve featuring a two-piece design made from stainless steel. It operates under a pressure rating of six hundred psi WOG. This valve is built for durability and reliability in various piping systems.

• Two-piece construction
• Full port design
• Manufactured from 304 stainless steel

Product Highlights

This valve is designed for easy installation and provides excellent flow characteristics due to its full port design. It is suitable for use in high-pressure applications.

Product Information

Standard Information

• Manufacturer: Jomar
• MPN: 100-111SSG

Technical Specifications

• Ball Material: 304 Stainless Steel
• Body Material: Brass
• End Style: FNPT
• Inlet to Outlet Length: 7.83 inches
• Nominal Size: 4 inches
• Port Type: Full
• Pressure Rating: 600 psi WOG
• Softgoods Material: Buna-N/PTFE
• Top to Inlet Center: 5.85 inches
• Trim Material: 304 Stainless Steel Stem and PTFE Seat
• Type: 2-Piece
