JOMAR 100-109SSG Full Port, 2 Piece, Threaded Connection, 600 WOG, Stainless Steel Ball

Product Description

The JOMAR 100-109SSG is a stainless steel ball valve designed for piping applications. This two-piece valve features a full port design, allowing for optimal flow in a compact form. The threaded connection ensures a secure fit, with a pressure rating of six hundred WOG. This valve is suitable for various plumbing and industrial applications.

• Body made from brass for durability
• Leak tested for reliability
• Features softgoods made of Buna-N and PTFE

Product Highlights

This valve is essential for controlling liquid and gas flow in pipe systems.

Product Information

Standard Information

• Brand: JOMAR
• MPN: 100-109SSG

Technical Specifications

• Ball Material: 304 Stainless Steel
• Body Material: Brass
• End Style: NPT
• Inlet to Outlet Length: 5.59 inches
• Nominal Size: 2-1/2 inches
• Port Type: Full
• Pressure Rating: 600 psi WOG
• Softgoods Material: Buna-N/PTFE
• Top to Inlet Center: 4-1/2 inches
• Trim Material: 304 Stainless Steel Stem and PTFE Seat
• Type: 2-Piece
