Jomar 100-106SSG Full Port, 2 Piece, Threaded Connection, 600 WOG, Stainless Steel Ball and

Product Description

The Jomar 100-106SSG is a two-piece stainless steel ball valve with a nominal size of one and one-quarter inches. It features a threaded end style suitable for a wide range of applications involving liquids and gases. This valve is designed to handle a pressure rating of six hundred psi WOG.

• Durable stainless steel ball
• Lead-free brass body
• 100% leak tested for safety

Product Highlights

This ball valve is ideal for HVAC, plumbing, and industrial applications. Its robust construction ensures reliable performance under pressure. The valve includes features to enhance its usability, like a blow-out proof stem and a single O-ring design for improved sealing.

Product Information

Standard Information

• Manufacturer: Jomar
• Part Number: 100-106SSG

Technical Specifications

• Ball Material: 304 Stainless Steel
• Body Material: Brass
• Nominal Size: 1-1/4 inches
• Orifice Size: 1.26 inches
• Inlet to Outlet Length: 3.45 inches
• Pressure Rating: 600 psi WOG
• Softgoods Material: PTFE/Buna-N
• Trim Material: 304 Stainless Steel Stem and PTFE Seat
