Jomar 100-102SSG Full Port, 2 Piece, Threaded Connection, 600 WOG, Stainless Steel Ball and

Product Description

The Jomar 100-102SSG is a 2-piece ball valve. It features a full port design with a threaded connection suitable for various applications. This valve is made from stainless steel and has a working pressure rating of 600 WOG.

• Full Port Design
• Durable Stainless Steel Construction
• Threaded Connection for Easy Installation

Product Highlights

Efficient flow and reliable sealing are provided by the Jomar 100-102SSG. Its stainless steel ball and stem ensure durability in high-pressure environments. This valve is ideal for plumbing systems where reliable shutoff is necessary.

Product Information

Standard Information

• Manufacturer: JOMAR
• MPN: 100-102SSG

Technical Specifications

• Ball Material: 304 Stainless Steel
• Body Material: Brass
• End Style: NPT
• Nominal Size: 3/8 inches
• Inlet to Outlet Length: 1.73 inches
• Pressure Rating: 600 psi WOG
• Softgoods Material: Buna-N/PTFE
• Port Type: Full
• Trim Material: 304 Stainless Steel Stem and PTFE Seat
