Johnson Controls VG7443GT+72CHGA Globe Valve Assembly 2 Way 1/2 in.

Product Description

The Johnson Controls VG7443GT+72CHGA is a globe valve assembly designed for effective control in HVAC systems. It features a two-way design with a nominal diameter of one-half inch. The valve is constructed from durable bronze and incorporates a stainless steel stem and seat for increased reliability.

• Electric actuator with a power rating of 24 VAC
• Flow coefficient (Cv) of 4.6 for efficient operation
• Spring return mechanism for quick valve closure

Product Highlights

The VG7443GT+72CHGA valve meets the requirements of ASME B16.15 Class 250 and is tested for tight shutoff, ensuring reliable performance in various applications.

Product Information

Standard Information

• Brand: Johnson Controls
• Item Number: VG7443GT+72CHGA

Technical Specifications

• Housing: NEMA 2, IP54
• Service: Hot Water, Chilled Water, 50/50 Glycol Solutions, and 38 psig Saturated Steam for HVAC Systems
• Closeoff Pressure: 308 psig
• Power Consumption: 6 VA
• Flow Characteristic: Equal Percentage
• Operating Conditions: 35 F to 338 F (2 C to 170 C)
• Electrical Connection: 48 in. UL 758 Type AWM Halogen-Free Cable with 18 AWG Conductors and 0.25 in. Ferrule Ends
• Actuator Operating Conditions: 23 F to 121 F (-5 C to 55 C)
