Johnson Controls VG7441ST+3008D Brass Trim Globe Valve with Exposed Pneumatic Actuator 4-8 psig Spring Range

Product Description

The Johnson Controls VG7441ST+3008D Brass Trim Globe Valve with Exposed Pneumatic Actuator controls hot or chilled water or 38 psig saturated steam. It features a factory or field assembly and operates with fluid temperatures between 35 to 284 degrees Fahrenheit. This valve includes a rugged actuator die-cast enclosure that fits VG7000 Series valves 1/2 through 2 inches. Suitable for HVAC systems, its static pressure rating is ANSI Class 250. For an optional V-9502-90 Positioner, add a P to the end of the code number.

• Brass trim for durability
• Temperature range of 35 to 284 degrees Fahrenheit
• Static pressure rating: ANSI Class 250

Product Highlights

The Johnson Controls VG7441ST+3008D pneumatic valve is perfect for hot or chilled water control in HVAC systems. It features a robust actuator and a spring range of 4-8 psi, ensuring reliable performance in various conditions.

Product Information

Standard Information

• Brand: Johnson Controls
• MPN: VG7441ST+3008D
• Model: VG7000

Technical Specifications

• Valve Size: 2 inches
• Valve Connection: NPT
• Piping Configuration: Straight
• Body Material: Bronze
• Valve Application: Steam, Water
• Max Pressure: 15 psi WSP, 125 psi WOG
• Weight: 16 lbs
