Johnson Controls VG7441RT+3008E Globe Valve Assembly 2-way 1-1/2 in

Product Description

The Johnson Controls VG7441RT+3008E is a two-way globe valve assembly designed for HVAC applications. It features a one and a half inch National Pipe Thread connection, suitable for high-pressure systems. The valve's body is made from bronze, ensuring durability and resistance to corrosion.

• Pressure rating of ANSI Class 250
• Maximum flow rate of 28.9 Cv
• Suitable for hot water, chilled water, and steam

Product Highlights

The VG7441RT+3008E is equipped with a pneumatic actuator and supports straight piping configurations. This valve is ideal for regulating steam and water flow in various HVAC systems.

Product Information

Standard Information

• Brand: Johnson Controls
• MPN: VG7441RT+3008E

Technical Specifications

• Valve Size: 1-1/2 inches
• Body Material: Bronze
• Valve Connection: NPT
• Max Pressure: 15 psi WSP, 125 psi WOG
• Operating Conditions: 35 F to 248 F
• Actuator Operating Conditions: -20 F to 150 F
• Flow Characteristic: Equal Percentage
• Closeoff Pressure: 23 psig
