Johnson Controls VG7441NT+3008BP Globe Valve Assembly 2 Way 1 in.

Product Description

The Johnson Controls VG7441NT+3008BP is a globe valve assembly designed for two-way flow control. This valve features a bronze body with a stainless steel stem and a molded elastomeric disk seat. It operates with a pneumatic actuator and includes a barbed fitting for tubing. This valve is ideal for various HVAC applications.

• Static pressure rating of ANSI Class 250.
• Compatible with hot water, chilled water, glycol solutions, and steam.
• Standard actuator operating conditions from -20 F to 150 F.

Product Highlights

The valve effectively regulates flow within HVAC systems, providing reliable performance across a range of operating conditions.

Product Information

Standard Information

• Brand: Johnson Controls
• Part Number: VG7441NT+3008BP

Technical Specifications

• Body Material: Bronze
• Flow Characteristic: Equal Percentage
• Closeoff Pressure: 17 psig
• Operational Temperature Range: 35 F to 248 F
• Spring Range: 3 to 6 psig
• Actuator Operating Conditions: -20 F to 150 F
• Pressure Rating: ANSI Class 250
• Service Compatibility: Hot water, chilled water, glycol solutions, steam
