Johnson Controls VG7281NT+7152G Globe Valve Assembly, 2 Way 1 in.

Product Description

The Johnson Controls VG7281NT+7152G is a two-way globe valve assembly designed for HVAC applications. It features a union sweat connection and a bronze body construction. This valve has an eleven point six Cv flow coefficient, which indicates its efficiency in managing fluid flow. The stainless steel stem and brass against molded elastomeric disk seat ensure durability and reliability.

• Magnetic clutch protects gearing and ensures tight closeoff.
• Valve body static pressure rating: ANSI Class 250.
• Direct mount electric actuator with spring return.

Product Highlights

This valve is suitable for hot water, chilled water, glycol solutions, and steam applications. It operates under various temperatures and conditions.

Product Information

Standard Information

• Brand: Johnson Controls
• Part Number: VG7281NT+7152G

Technical Specifications

• Housing: NEMA 2, IP42
• Service: Hot Water, Chilled Water, 50/50 Glycol Solutions, and Steam for HVAC Systems
• Closeoff Pressure: 86 psig
• Power Consumption: 4.7 VA
• Flow Characteristic: Equal Percentage
• Operating Conditions: 35 F to 284 F (2 C to 140 C)
• Electrical Connection: Screw terminals for 16 AWG maximum
• Actuator Operating Conditions: 0 F to 140 F (-18 C to 60 C)
