Product Description
The Johnson Controls VG7251CT+7150G is a globe valve assembly designed for use in various HVAC applications. This 2-way valve offers reliable performance with a flow coefficient of 0.73. It features a bronze body, stainless steel stem, and a molded elastomeric disk seat. The unit is equipped with a direct coupled electric actuator, ensuring effective control in on/off and floating scenarios.
- Designed for hot water, chilled water, and steam systems
- Rated for a static pressure of 345 psig
- Operating conditions range from 35°F to 284°F
Product Highlights
This valve assembly incorporates advanced features like a magnetic clutch to protect the gearing and ensure tight closeoff. The installation is straightforward thanks to screw terminals accommodating up to 16 AWG wires.
Product Information
Standard Information
-
Brand: Johnson Controls
-
Part Number: VG7251CT+7150G
Technical Specifications
-
Housing: NEMA 2, IP42
-
Flow Characteristic: Equal Percentage
-
Power Consumption: 2.7 VA
-
Closeoff Pressure: 345 psig
-
Operating Conditions: 35°F to 284°F (2°C to 140°C)
-
Actuator Operating Conditions: 0°F to 140°F (-18°C to 60°C)
-
Service: Hot water, chilled water, glycol solutions, and steam for HVAC systems
-
Electrical Connection: Screw terminals for 16 AWG maximum
