Johnson Controls VG7243RT+823D00 Stainless Steel Trim Globe Valve with MP823D001A Pneumatic Actuator 4-8 psig Spring Range

Product Description

The Johnson Controls VG7243RT+823D00 Stainless Steel Trim Globe Valve with Pneumatic Actuator is designed to control hot or chilled water and 100 psig saturated steam. Featuring an industrial-grade, drawn-steel actuator, this valve operates with a spring range of 4-8 psig, making it suitable for various HVAC applications.

• Controls hot or chilled water
• Handles 100 psig saturated steam
• Spring-loaded PTFE and elastomer V-rings

Product Highlights

This valve offers robust operation with a maximum supply air pressure of 25 psig. It supports fluid temperatures ranging from 35 to 338 degrees Fahrenheit, making it versatile for different environments. The valve body has a static pressure rating of ANSI Class 250, ensuring durability and reliability.

Product Information

Standard Information

• Manufacturer: Johnson Controls, Inc
• Brand: Johnson Controls
• Model: VG7243RT+823D00
• Category: HVAC Controls
• Product Group: BISS

Technical Specifications

• MPN: VG7243RT+823D00
• Fluid Temperature: 35 to 338 degrees Fahrenheit
• Supply Air Pressure: 25 psig
• Valve Body Rating: ANSI Class 250
• Maximum Steam Pressure: 100 psig
• Spring Range: 4-8 psig
• Actuator Material: Drawn-steel
