Johnson Controls VG7243RM+843E00 Stainless Steel Globe Valve 1 1/2 Inch

Product Description

The Johnson Controls VG7243RM+843E00 Stainless Steel Globe Valve is engineered for precise control of chilled or hot water and 100 psig saturated steam in HVAC systems. This valve features a robust pneumatic actuator and is suitable for applications requiring ANSI Class 250 pressure ratings.

• Designed for both hot and chilled water systems.
• Uses pneumatic actuation for reliable performance.
• Supports up to 100 psig saturated steam.

Product Highlights

This valve series offers superior durability and performance, with spring-loaded PTFE and elastomer V-rings for tight sealing and a maximum supply air pressure of 25 psig.

Product Information

Standard Information

• Brand: Johnson Controls
• Product Type: Valve

Technical Specifications

• Material: Stainless Steel Trim
• Fluid Temperature Range: 35 to 338 degrees Fahrenheit
• Maximum Supply Air Pressure: 25 psig
• Valve Size: 1 1/2 inches
• Spring Range: 9-13 psig
