Johnson Controls VG7243PT+3008E Stainless Steel Trim Globe Valve 1/4 NPT 18.5 W

Product Description

The Johnson Controls Series VG7000 Model VG7243PT Stainless Steel Trim Globe Valve with Model V-3000-8012 Exposed Pneumatic Actuator delivers precise control over your water or steam systems. Ideal for regulating both hot and chilled water or up to 100 psig saturated steam, these valves maintain a robust presence in any industrial setup.

• Operates efficiently with hot or chilled water
• Designed for systems up to 100 psig saturated steam
• ANSI Class 250 static pressure rating

Product Highlights

This valve is engineered with a rugged die-cast enclosure that is optimally suited for industrial environments. Its pneumatic actuators provide reliable performance for pipe sizes ranging from 1/2 inch to 1-1/4 inches. The fluid temperature can range from 35 to 338 degrees Fahrenheit, making it incredibly versatile for various operational demands.

Product Information

Standard Information

• Brand: Johnson Controls
• MPN: VG7243PT+3008E
• Valve Type: Globe Valve
• Actuator Type: Pneumatic

Technical Specifications

• Maximum Air Supply Pressure: 25 psig (172 kPa)
• Static Pressure Rating: ANSI Class 250
• Fluid Temperature Range: 35 to 338inchu00b0F (2 to 170inchu00b0C)
