Johnson Controls VG7243NT Stainless Steel Trim Globe Valve with V-3000 Exposed Pneumatic Actuator

Product Description

The Johnson Controls Series VG7000 Model VG7243NT Globe Valve is engineered for precise flow control of hot or chilled water and up to 100 psig of saturated steam. The valve features a V-3000 pneumatic actuator and is suitable for systems requiring a supply air pressure of up to 25 psig. Its fluid temperature range spans from 35 to 338 degrees Fahrenheit, making it versatile across different environments.

• Designed for robust applications with ANSI Class 250 pressure rating
• Compatible with hot or chilled water, and low pressure steam
• Can be factory or field assembled for flexible installation options

Product Highlights

This stainless steel trim globe valve offers dependable performance with its rugged actuator die-cast enclosure, compatible with VG7000 valves from 1/2 inch up to 1-1/4 inches.

Product Information

Standard Information

• Manufacturer: Johnson Controls
• Model: VG7243NT

Technical Specifications

• Fluid Temperature Range: 35 to 338°F
• Body Static Pressure Rating: ANSI Class 250
• Maximum Supply Air Pressure: 25 psig
• Valve Size Compatibility: 1/2 inch to 1-1/4 inches
