Johnson Controls VG7243GT+821C00 Series VG7000 Model Stainless Steel Trim Globe Valve with MP821C001B/MP822C001A/MP823C001A Pneumatic Actuator

Product Description

The Johnson Controls VG7243GT+821C00 is part of the VG7000 series and includes stainless steel trim globe valves. This valve works with MP82 series pneumatic actuators to effectively control hot or chilled water and can handle up to 100 psig saturated steam. With robust design features, it is suitable for various industrial applications.

• Compatible with hot and chilled water
• Maximum supply air pressure of 25 psig (172 kPa)
• Designed for fluid temperatures from thirty-five to three hundred thirty-eight degrees Fahrenheit (two to one hundred seventy degrees Celsius)

Product Highlights

This valve is equipped with a spring-loaded PTFE and elastomer V-ring packing for enhanced operation. Its body static pressure rating meets ANSI Class 250 standards and can be assembled in either factory or field settings.

Product Information

Standard Information

• Manufacturer: Johnson Controls, Inc.
• Product Type: Valve

Technical Specifications

• MPN: VG7243GT+821C00
• Spring Range: 3-7 psig
• Valve Body Pressure Rating: ANSI Class 250
• Fluid Temperature Range: 35 to 338 °F (2 to 170 °C)
• Maximum Supply Air Pressure: 25 psig (172 kPa)
• Weight: 0.6 lbs
• Number of Items: 1
