Johnson Controls VG7243ET+7152G Stainless Steel Trim Globe Valve 24V

Product Description

The Johnson Controls VG7243ET+7152G is a high-performance stainless steel trim globe valve, equipped with a VA-7152-1001 non-spring return electric actuator, designed for precise control of hot or chilled water and steam in HVAC systems. This model falls under the VG7000 series and is suitable for valves ranging from 1/2 inch to 2 inches.

• Compatible with VG7000 series valves, enhancing versatility.
• Static pressure rating meets ANSI Class 250 standards.
• Operates on 24 VAC, 50/60 Hz, drawing 4.7 VA.

Product Highlights

The 90 lb. force ensures reliable tight close-off, ideal for effective flow management in a variety of environmental conditions.

Product Information

Standard Information

• Brand: Johnson Controls
• MPN: VG7243ET+7152G

Technical Specifications

• Valve Type: Stainless Steel Trim Globe Valve
• Actuator Model: VA-7152-1001 Non-Spring Return Electric
• Compatible Valve Sizes: 1/2 inch to 2 inches
• Power Input: 24 VAC, 50/60 Hz, 4.7 VA
• Pressure Rating: ANSI Class 250
