Product Description
The JOHNSON CONTROLS VG7241CT+3008B globe valve assembly is a 2-way valve with a 1/2 inch NPT connection and a 0.73 Cv flow coefficient. It features a bronze body, stainless steel stem, and brass seat, along with a pneumatic actuator with spring return. It also includes a 1/8 inch NPT barbed fitting for 1/4 inch or 5/32 inch O.D. polytubing and operates with 3 to 6 psig.
- Rugged Actuator Die-Cast Enclosure
- Enclosed Spring
- Factory Or Field Assembly
Product Highlights
This globe valve assembly is designed for HVAC systems using hot water, chilled water, glycol solutions, and steam.
Product Information
Standard Information
-
Brand: JOHNSON CONTROLS
-
Manufacturer Part Number: VG7241CT+3008B
-
Country of Origin: Mexico
Technical Specifications
-
Housing: Die Cast Aluminum Diaphragm, Synthetic Rubber
-
Service: Hot Water, Chilled Water, 50/50 Glycol Solutions, And Steam For HVAC Systems
-
Flow Characteristic: Equal Percentage
-
Operating Conditions: 35 F To 248 F (2 C To 120 C)
-
Operating Conditions (Actuator): -20 F To 150 F (-29 C To 66 C)
-
Brand: Johnson Controls
-
Product Type: 2-Way Normally Open
-
Size: 1/2IN
-
End Connection: NPT
-
Material: Bronze
-
Pressure: 365PSIG Close Off
-
Temperature: 35 to 284DEG F
-
Application: HVAC System
-
MPN: VG7241CT+3008B
-
Model: VG7000
-
Valve Size: 1/2"
-
Valve Connection: NPT
-
Piping Configuration: Straight
-
Body Material: Bronze
-
Valve Application: Steam, Water
-
Max Pressure: 15 psi WSP, 125 psi WOG
-
CV: 0.73
-
Trim: Brass
-
Linkage: VG7000-1001
-
Actuator: 3008B
-
Assembly: Assembly
-
Pipe Size: 0.5 in
-
Power Supply: Pneumatic
-
Spring Range: 3-6 PSI
-
Valve Number: VG7241CT
-
Close Off Pressure: 365 PSI
-
Fail Safe Position: Normally Open
-
Item Number: VG7241CT+3008B
-
Actuator Type: Pneumatic
-
Connection Type: Threaded
-
Flow Capacity (Cv): 0.73
-
Body Pattern: 2-Way
-
Fail-Safe: Spring Return
-
Control Signal: Pneumatic
-
MEDIUM: WATER & STEAM
-
DIAPHRAGM AREA: 8 SQ. IN.
-
FAIL POSITION: NORMALLY OPEN
-
BODY RATING: 250
-
CONNECTION: FEMALE NPT
-
TRIM MATERIAL: BRASS
-
POSITIONER: NONE
