Johnson Controls VG2831UN+865C01 Globe Valve Assembly 3 Way 3 in

Product Description

The Johnson Controls VG2831UN+865C01 is a three-way globe valve assembly designed for HVAC applications. The valve is made of cast iron with a stainless steel stem and a brass plug, ensuring reliable operation in heating and cooling systems. This valve operates within a spring range of three pounds per square inch gauge (psig) to seven psig.

• Flanged design compatible with ANSI B16.1 standards.
• Leakage of only 0.1 percent of maximum flow for reliable sealing.
• Field reversible spring action for flexible installation.

Product Highlights

This valve is suitable for services including hot water, chilled water, glycol solutions, and steam.

Product Information

Standard Information

• Brand: Johnson Controls
• Part Number: VG2831UN+865C01

Technical Specifications

• Service: Hot Water, Chilled Water, 50/50 Glycol Solutions, And Steam For HVAC Systems
• Close-Off Pressure: 91/21 psig
• Flow Characteristic: Modified Linear
• Operating Conditions: 35 F To 281 F (2 C To 138 C)
