Johnson Controls VG2431UN Iron 2-Way Normally Closed Flanged Globe Valve

Product Description

The Johnson Controls VG2431UN Iron 2-Way Normally Closed Flanged Globe Valve is meticulously designed to manage water and steam flow in HVAC systems. This valve is well-suited for use with the M9000 series and pneumatic actuators.

• Robust cast iron construction ensures long-lasting performance.
• Brass trim enhances durability and resistance to corrosion.
• Tested for leakage to guarantee reliability and efficiency.

Product Highlights

This valve series is available in sizes 2-1/2 to 6 inches, ideal for diverse HVAC applications. It features a flanged connection type and is versatile for both factory and field installations.

Product Information

Standard Information

• Valve Type: Iron Flanged Globe Valve
• Operation: Normally Closed

Technical Specifications

• Body Material: Cast iron
• Trim Material: Brass
• Connection Size: 3 inches
• Connection Type: Flanged
• Maximum Water Temperature: 281 degrees Fahrenheit
• Coefficient of Volume: 83
• Safe Working Steam Pressure: 35 psi
• Safe Working Water Pressure: 170 psi
