Johnson Controls VG1845CL Ball Valve, 3 Way, 1 in. 7.4 Cv

Product Description

The Johnson Controls VG1845CL is a three-way ball valve designed for efficient fluid control in HVAC systems. It measures one inch with a flow capacity of 7.4 Cv. This valve is made of forged brass with a stainless steel ball and features a blowout-proof stem for safety.

• Designed for hot water, chilled water, and steam service.
• Maintenance-free design for reliable performance.
• Rated for 200 psi close-off pressure and temperatures from -22°F to 284°F.

Product Highlights

Efficient flow regulation through three available ports ensures effective HVAC system management.

Product Information

Standard Information

• Brand: Johnson Controls
• Part Number: VG1845CL

Technical Specifications

• Service: Hot Water, Chilled Water, Glycol Solutions, Saturated Steam
• Close-Off Pressure: 200 psi
• Flow Characteristic: Equal Percentage and Linear
• Operating Conditions: -22°F to 284°F
• Material: Brass and Stainless Steel
• Dimensions: Length - 3 inches, Width - 2 inches, Height - 2 inches
• Weight: 0.1 lbs
• Flow Capacity (Cv): 7.4
