Johnson Controls VG1845BNH943BGB 3-Way Ball Valve Assembly 24 VAC (3/4 in.)

Product Description

Johnson Controls VG1845BNH943BGB is a 3-way ball valve assembly with a direct-mount electric actuator for on/off HVAC control. The 3/4 in. NPT valve provides an 11.7 Cv flow coefficient, a forged brass body with stainless steel ball and a blowout-proof stem. The actuator is 24 VAC with spring-return torque and includes a single SPDT auxiliary switch; suitable for hot water, chilled water, and 50/50 glycol service.

• 3-way 3/4 in. NPT ball valve, 11.7 Cv, forged brass body with stainless steel trim and blowout-proof stem
• Direct-mount 24 VAC spring-return electric actuator (27 lb-in), on/off operation with 1 x SPDT auxiliary switch
• Low power consumption (5.0 VA running, 2.5 VA holding), 200 psig close-off pressure, NEMA 2 / IP54 housing

Product Highlights

3/4 in. 3-way ball valve assembly, 11.7 Cv, 24 VAC spring-return actuator for HVAC water and glycol systems

Product Information

Standard Information

• Brand: JOHNSON CONTROLS
• Manufacturer Part Number: VG1845BNH943BGB
