Johnson Controls VG1845BNH943BGA Ball Valve Assembly 24 VAC (3/4 In.)

Product Description

Johnson Controls VG1845BNH943BGA is a 3/4 inch, 3-way ball valve assembly with a 24 VAC direct-mount spring-return electric actuator for on/off operation. The valve features a forged brass body, stainless steel ball, and blowout-proof stem with an 11.7 Cv rating, NPT connections, and suitability for hot water, chilled water, and 50/50 glycol HVAC service across -22 F to 140 F. Housing is NEMA 2/IP54 with 48 in. 18 AWG electrical leads.

• Direct-mount 2-position spring-return actuator, 27 lb-in torque, on/off function, 24 VAC control
• Forged brass body with stainless steel ball, blowout-proof stem, 11.7 Cv (A port) / 5.8 Cv (B port)
• Rated for HVAC fluids (hot/chilled water, 50/50 glycol), operating temperature -22 F to 140 F; power 5.0 VA running, 2.5 VA holding

Product Highlights

3/4 in three-way NPT ball valve assembly with 24 VAC spring-return actuator, 11.7 Cv, forged brass body, NEMA 2/IP54 housing

Product Information

Standard Information

• Brand: JOHNSON CONTROLS
• Manufacturer Part Number: VG1845BNH943BGA
