Johnson Controls VG1845BN+943BUA 3-Way Ball Valve Assembly 85-264 VAC (3/4 in.)

Product Description

Johnson Controls VG1845BN+943BUA is a 3-way 3/4 in. ball valve assembly with an 11.7 Cv flow coefficient and a direct-mount spring-return electric actuator. The valve features a forged brass body, stainless steel ball and blowout-proof stem, NPT threaded connections, and a 200 psig close-off rating for HVAC hot water, chilled water, and 50/50 glycol service. Actuator torque is 27 lb-in, voltage 85–264 VAC, housing NEMA 2/IP54.

• 3-way forged brass ball valve, 3/4 in. NPT, Cv 11.7 (A port); 5.8 (B port)
• Direct-mount spring-return electric actuator, 27 lb-in torque, 85–264 VAC, on/off control
• NEMA 2/IP54 housing, 200 psig close-off rating, operating temperature -22°F to 140°F (-30°C to 60°C)

Product Highlights

3/4 in. 3-way HVAC ball valve assembly with stainless steel trim, 11.7 Cv, and 85–264 VAC spring-return actuator

Product Information

Standard Information

• Brand: JOHNSON CONTROLS
• Manufacturer Part Number: VG1845BN+943BUA
