Johnson Controls VG1841AL+923AGA 1/2 NPT 3-Way Brass Valve w/ VA9203 On/Off and Floating Point (7.4 Cv)

Product Description

The Johnson Controls VG1841AL+923AGA is a 1/2 inch NPT 3-way brass valve designed for HVAC applications. This valve operates with a VA9203 actuator, providing on/off and floating point control. It is ideal for regulating the flow of hot or chilled water, and in some cases, low pressure steam. This valve is suitable for use in heating, ventilating, and air conditioning systems.

• Flow capacity of 7.4 Cv
• Temperature range from twenty-three to two hundred three degrees Fahrenheit
• Threaded connection type

Product Highlights

The VG1841AL+923AGA valve offers reliable control in various HVAC systems.

Product Information

Standard Information

• Manufacturer: Johnson Controls
• MPN: VG1841AL+923AGA
• Body Pattern: 3-Way

Technical Specifications

• Power Requirements: 24 VAC +/- 20%, VDC +/- 10%
• Flow Capacity (Cv): 7.4
• Fail Safe Mode: Port A Open, Spring Return
• Actuator Type: On/Off, Floating Point
• Shipping Weight: 5 lbs
• Dimensions: 5 x 5 x 3 inches
• Material: Brass
• Connection Type: Threaded
