Johnson Controls VG1245FT+938GGC Two-Way Stainless Steel Trim NPT End Connection Ball Valve with Electric Actuator

Product Description

The Johnson Controls VG1245FT+938GGC is a high-quality two-way ball valve designed for reliable performance in HVAC systems. This package includes an electric actuator for effective flow regulation of hot or chilled water, and potentially low-pressure steam.

• Equipped with a VA9208-GGC-3 open spring-return electric actuator for precise control.
• Features a robust stainless steel trim that ensures long-term durability.
• Designed for easy integration into various HVAC setups with its NPT end connections.

Product Highlights

With a flow capacity of 73.7 Cv, this valve assembly is ideal for a wide range of heating and cooling applications. It is capable of handling fluid temperatures ranging from -22 to 212 degrees Fahrenheit, making it a versatile choice for different environmental conditions.

Product Information

Standard Information

• Brand: Johnson Controls
• MPN: VG1245FT+938GGC
• Product Type: Valve

Technical Specifications

• Connection Type: Threaded
• Body Pattern: 2-Way
• Actuator Type: Proportional, Spring Return
• Electrical Connections: 48 inches 18 AWG Appliance Cable
• Power Requirements: 24 VAC +/- 20%, VDC +/- 10%
• Position Feedback: 0(2) to 10 VDC
• Fail Safe Mode: Spring Return, Port A Open
• Weight: 5 lbs
