Johnson Controls VG1245FR+958GGC Ball Valve Assembly 2 Way 2 in.

Product Description

The Johnson Controls VG1245FR+958GGC is a ball valve assembly designed for efficient flow control in HVAC systems. This 2-way valve is constructed from forged brass and is designed to accommodate a wide range of operating conditions.

• Maintenance-free design
• Direct mount electric actuator
• Capable of handling 200 psig close-off pressure

Product Highlights

This valve offers high reliability and performance. It operates with a 29.2 Cv and integrates a stainless steel ball and blowout-proof stem, ensuring longevity and durability in demanding environments.

Product Information

Standard Information

• Brand: Johnson Controls
• Part Number: VG1245FR+958GGC

Technical Specifications

• Housing: NEMA 2, IP54
• Service: Hot Water, Chilled Water, 50/50 Glycol Solution, and 15 psig Saturated Steam for HVAC
• Flow Characteristic: Equal Percentage
• Power Consumption: 7.9 VA Running, 5.5 VA Holding
• Operating Conditions: -40 F to 140 F (-40 C to 60 C)
• Auxiliary Switch: 2 x SPDT
• Electrical Connection: 48 in. 18 AWG appliance cable with integral 3/8 in. FMC connectors
• Close-Off Pressure: 200 psig
