Johnson Controls VG1245EP+938BAA Two-Way Stainless Steel Trim Ball Valve NPT 120V On/Off Actuator

Product Description

The Johnson Controls VG1245EP+938BAA is a two-way stainless steel trim ball valve paired with a VA9208 series 120V on/off non-spring-return electric actuator. Designed for HVAC systems, this valve controls the flow of hot or chilled water and low-pressure steam.

• High static pressure rating of 580 psig.
• Capable of 200 PSID close-off pressure.
• Weather shield options available for robust outdoor usage.

Product Highlights

This assembly features a durable forged brass body and is suitable for creating efficient, responsive HVAC systems.

Product Information

Standard Information

• Brand: Johnson Controls
• MPN: VG1245EP+938BAA

Technical Specifications

• Body Material: Stainless Steel
• Connection Type: NPT threaded
• Size: 1-1/2 inches
• Actuator Type: 120V on/off
• Flow Capacity (Cv): 18.7
• Temperature Range: -22 to 212 degrees Fahrenheit
• Electrical Requirements: 120 VAC +10%/-15% at 60 Hz
• Actuator Cable: 48 inches 18 AWG appliance cable
