Johnson Controls VG1245DP+928AGA Two-Way Stainless Steel Ball Valve with Electric Actuator

Product Description

The Johnson Controls VG1245DP+928AGA is a two-way stainless steel ball valve equipped with the VA9208 Series Spring-Return Electric Actuator. This valve is utilized in HVAC systems and is engineered to regulate the flow of hot or chilled water and, for certain models, low-pressure steam in response to a controller's demand.

• Durable forged brass body.
• Supports on/off, floating, or proportional control.
• Integrates seamlessly with Johnson Controls VA9104, M9106, M9109, M9100 Series Non-Spring Return, and VA9203, VA9208 Series Spring-Return Electric Actuators.

Product Highlights

This valve assembly provides reliable operation with its high static pressure rating of 580 psig. It features a 24 VAC power requirement and supports electrical connections through a 120-inch plenum cable. Designed for both commercial and industrial applications, it offers a broad temperature range and versatile control options.

Technical Specifications

• Body Material: Forged Brass
• Actuator Type: Spring Return, Electric
• Pressure Rating: 580 psig
• Temperature Range: -22 to 212 degrees Fahrenheit
• Control Options: On/off, floating, or proportional control
• Connection Type: Threaded NPT
• Power Requirements: 24 VAC, +/- 20%, VDC +/- 10%
