Johnson Controls VG1245CN+923GGA Two-Way Stainless Steel Trim NPT Ball Valve with Open Non-Spring-Return Electric Actuator

Product Description

This Johnson Controls VG1245CN+923GGA Two-Way Stainless Steel Trim NPT Ball Valve is designed to regulate the flow of hot or chilled water and, in some models, low-pressure steam in HVAC systems. This valve comes factory or field mounted to a VA9203-GGA-2Z Open Non-Spring-Return Electric Actuator.

• Stainless steel construction.
• Static pressure rating of 580 psig.
• Threaded connection type.

Product Highlights

An efficient solution for regulating various types of fluid flow in HVAC systems. Ideal for commercial and industrial applications.

Product Information

Standard Information

• Category: HVAC Controls, Categories
• Sub-Category: HVAC Actuators and Valves

Technical Specifications

• Power Requirements: 24 VAC +/- 20%, VDC +/- 10%
• Position Feedback: 0(2) to 10 VDC
• Electrical Connections: 120 in. (3.05 m) 19 AWG Plenum Cable
• Weather Shield Options: M9000-341
• Close Off Pressure: 200 PSID
• Flow Capacity: 11.7 Cv
• Fluid Temperature Range: -22°F to 212°F
• Torque: 27 lb-in
• Material: Stainless Steel
• Body Pattern: 2-Way
• Actuator Type: Proportional, 0 (4) to 20 mA, with 500 ohm resistor, 0 (2) to 10 VDC
• Fail Safe Mode: Spring Return, Port A Open
