Johnson Controls VG1245CLH9T4IGA Ball Valve Assembly 2 Way 1 in.

Product Description

The Johnson Controls VG1245CLH9T4IGA is a two-way ball valve assembly designed for effective control in HVAC systems. This product is suitable for various applications, such as hot water, chilled water, and glycol solutions. It features a forged brass body with a stainless steel ball and a blowout-proof stem. The direct mount electric actuator is reliable and supports both on/off and floating control modes.

• NPT connection with a flow coefficient (Cv) of 7.4
• Operating temperatures range from -4 F to 140 F
• Closed off pressure of 200 psig

Product Highlights

Features a 500:1 rangeability for accurate control under varying load conditions.

Product Information

Standard Information

• Brand: Johnson Controls
• Part Number: VG1245CLH9T4IGA

Technical Specifications

• Housing: NEMA 1, IP40
• Service: Suitable for hot water, chilled water, glycol solutions, and saturated steam at up to 15 psig
• Power Consumption: 3.0 VA
• Flow Characteristic: Equal percentage
• Operating Conditions: -4 F to 140 F (-20 C to 60 C)
• Electrical Connection: M3 screw terminals
