Johnson Controls VG1245CLH923GGB Ball Valve Assembly 2 Way 1 in.

Product Description

The Johnson Controls VG1245CLH923GGB is a two-way ball valve assembly designed for effective flow control in HVAC systems. This valve operates at a one-inch size and features a forged brass body with a stainless steel ball and blowout-proof stem. It is compatible with direct mount electric actuators and supports a spring return of twenty-seven pound-inches. The valve works with 24 VAC control signals and provides a proportional output of 0 to 10 VDC, ensuring optimal performance in various applications.

• Maintenance-free design ensures reliability.
• High rangeability of 500:1 for precise control.
• Durable construction for long service life.

Product Highlights

This ball valve assembly is ideal for use in hot and chilled water systems, as well as glycol solutions and steam systems.

Product Information

Standard Information

• Brand: Johnson Controls
• Part Number: VG1245CLH923GGB

Technical Specifications

• Housing: NEMA 2, IP54
• Service: Hot Water, Chilled Water, 50/50 Glycol Solution, 15 psig Saturated Steam
• Auxiliary Switch: 1 x SPDT
• Power Consumption: 5.1 VA Running, 2.8 VA Holding
• Close-Off Pressure: 200 psig
• Flow Characteristic: Equal Percentage
• Operating Conditions: -22 F To 140 F
• Electrical Connection: 48 in. 18 AWG Appliance Cables With Integral 3/8 in. FMC Connectors
