Johnson Controls VG1245CLH923BUA Ball Valve Assembly 2 Way 1 in.

Product Description

The Johnson Controls VG1245CLH923BUA is a two-way ball valve assembly designed for HVAC systems. This valve features a one-inch size and operates at a flow coefficient of seven point four. It is made from forged brass and features a stainless steel ball, which promotes durability and reliability. The valve is designed for direct mounting of electric actuators and can function with voltages ranging from eighty-five to two hundred sixty-four VAC.

• Maintenance-free design ensures long-lasting performance.
• Operates effectively in hot water, chilled water, and glycol solutions.
• Rated for a close-off pressure of two hundred psig.

Product Highlights

This valve assembly performs without failure beyond two hundred thousand full stroke cycles in contaminated water and offers an impressive rangeability of five hundred to one, facilitating accurate control under varying load conditions.

Product Information

Standard Information

• Brand: Johnson Controls
• Part Number: VG1245CLH923BUA

Technical Specifications

• Housing: NEMA 2, IP54
• Service: Hot Water, Chilled Water, 50/50 Glycol Solution, and 15 psig Saturated Steam
• Power Consumption: 0.06 Amp Running, 0.02 Amp Holding
• Close-Off Pressure: 200 psig
• Flow Characteristic: Equal Percentage
• Operating Conditions: -22 F to 140 F (-30 C to 60 C)
• Electrical Connections: 48 in. 18 AWG Appliance Cables with Integral 3/8 in. FMC Connectors
