Johnson Controls VG1245CLH923AGA Ball Valve Assembly 2 Way 1 in.

Product Description

The Johnson Controls VG1245CLH923AGA is a two-way ball valve assembly designed for effective control in HVAC applications. This valve is one inch in size and features a durable forged brass body that ensures longevity and reliability. It operates with a stainless steel ball and a blowout-proof stem, minimizing the risk of leaks and failures.

• Maintenance-free design
• Suitable for hot and chilled water systems
• Direct mount electric actuator with spring return

Product Highlights

This valve assembly is engineered to perform without failure in excess of two hundred thousand full stroke cycles, even in contaminated water. Its design includes a five hundred to one rangeability, allowing for accurate control under various load conditions.

Product Information

Standard Information

• Brand: Johnson Controls
• Part Number: VG1245CLH923AGA

Technical Specifications

• Power Consumption: 5.1 VA running, 2.8 VA holding
• Close-Off Pressure: 200 psig
• Flow Characteristic: Equal Percentage
• Operating Conditions: -22 F to 140 F (-30 C to 60 C)
• Electrical Connections: 120 inches 19 AWG plenum cable with integral 3/8 inch FMC connectors
• Housing: NEMA 2, IP54
• Service: Suitable for hot water, chilled water, 50/50 glycol solution, and 15 psig saturated steam
